6: ALLOCATION NUMBERS
6-12 OPENNET CONTROLLER USER’S MANUAL
Special Data Registers
Special Data Register Allocation Numbers
Allocation
Number
Description Updated See Page
D8000 System Setup ID (Quantity of Inputs) When I/O initialized
D8001 System Setup ID (Quantity of Outputs) When I/O initialized
D8002 System Setup ID (Quantity of Functional Modules) When I/O initialized
D8003 System Setup ID (Data Link Usage) — 1: Yes, 0: No When I/O initialized
D8004 System Setup ID (INTERBUS Master Usage) — 1: Yes, 0: No When I/O initialized
D8005 General Error Code When error occurred 27-3
D8006 User Program Execution Error Code When error occurred 27-6
D8007 User Program Execution Error Address When error occurred 27-6
D8008 Year (Current Data) Read only Every 100 msec 15-7
D8009 Month (Current Data) Read only Every 100 msec 15-7
D8010 Day (Current Data) Read only Every 100 msec 15-7
D8011 Day of Week (Current Data) Read only Every 100 msec 15-7
D8012 Hour (Current Data) Read only Every 100 msec 15-7
D8013 Minute (Current Data) Read only Every 100 msec 15-7
D8014 Second (Current Data) Read only Every 100 msec 15-7
D8015 Year (New Data) Write only 15-7
D8016 Month (New Data) Write only 15-7
D8017 Day (New Data) Write only 15-7
D8018 Day of Week (New Data) Write only 15-7
D8019 Hour (New Data) Write only 15-7
D8020 Minute (New Data) Write only 15-7
D8021 Second (New Data) Write only 15-7
D8022 Constant Scan Time Preset Value 5-20
D8023 Scan Time (Current Value) Every scan 5-20
D8024 Scan Time (Maximum Value) At occurrence 5-20
D8025 Scan Time (Minimum Value) At occurrence 5-20
D8026 Communication Selector Switch Value (0 through 7) Power-up
D8027 Communication Device Number (0 through 31) Power-up
D8028 Internal System Program Version Power-up
D8029 External System Program Version Power-up
D8030 Protect Transistor Output Error (1st) — 1: Error, 0: No error When error occurred 2-20
D8031 Protect Transistor Output Error (2nd) — 1: Error, 0: No error When error occurred 2-20
D8032 Protect Transistor Output Error (3rd) — 1: Error, 0: No error When error occurred 2-20
D8033 Protect Transistor Output Error (4th) — 1: Error, 0: No error When error occurred 2-20
D8034 Protect Transistor Output Error (5th) — 1: Error, 0: No error When error occurred 2-20
D8035 Protect Transistor Output Error (6th) — 1: Error, 0: No error When error occurred 2-20
D8036 Protect Transistor Output Error (7th) — 1: Error, 0: No error When error occurred 2-20
D8037-D8039 — Reserved ———
D8040 Advanced Instruction Error Address 1 At advanced inst. error
D8041 Advanced Instruction Error Address 2 At advanced inst. error
D8042 Advanced Instruction Error Address 3 At advanced inst. error
D8043 Advanced Instruction Error Address 4 At advanced inst. error
D8044 Advanced Instruction Error Address 5 At advanced inst. error
