IDEC OpenNet series User Manual

2: MODULE SPECIFICATIONS
OPENNET CONTROLLER USER’S MANUAL 2-13
FC3A-N32B4 (32-point DC Input Module) — Nylon Connector Type
Applicable Connector: H18-SHF-AA (J.S.T. Mfg.)
SHF-001T-0.8BS (J.S.T. Mfg.)
Wiring Schematic
• COM terminals are connected together internally.
• Terminal numbers are marked on the female connector on the cable.
• For wiring precautions, see page 3-5.
0
1
2
3
4
5
6
7
CN1
CN2
10
11
12
13
14
15
16
17
20
21
22
23
24
25
26
27
30
31
32
33
34
35
36
37
DC
IN
CN1
Terminal No. Name
18 I0
17 I1
16 I2
15 I3
14 I4
13 I5
12 I6
11 I7
10 I10
9 I11
8 I12
7 I13
6 I14
5 I15
4 I16
3 I17
2 COM
1 COM
CN2
Terminal No. Name
18 I20
17 I21
16 I22
15 I23
14 I24
13 I25
12 I26
11 I27
10 I30
9 I31
8 I32
7 I33
6 I34
5 I35
4 I36
3 I37
2 COM
1 COM
CN1
Terminal No. Name
18 I0
17 I1
16 I2
15 I3
14 I4
13 I5
12 I6
11 I7
10 I10
9 I11
8 I12
7 I13
6 I14
5 I15
4 I16
3 I17
2 COM
1 COM
CN2
Terminal No. Name
18 I20
17 I21
16 I22
15 I23
14 I24
13 I25
12 I26
11 I27
10 I30
9 I31
8 I32
7 I33
6 I34
5 I35
4 I36
3 I37
2 COM
1 COM
+
–
+
–
Source
Input
Wiring
Sink
Input
Wiring
