IEMCA Smart 320 Tp - Page 131

11 - COLLETS SMART320
EN
11 - Pag. 3 / 18
Y=Zx1,154 Y=Zx1,154
mm mm mm mm mm mm
23 26.55 26.2 72 83.08 82.5
24 27.71 27.5 75 86.55 86
25 28.86 28.5 80 92.32 91.75
26 30.02 29.8 85 98.1 97.5
27 31.17 31
