EN
6 - USE AND OPERATION SMART320
6 - Pag. 20 / 22
6.7 AXIS CALIBRATION PROCEDURE
Foreword:
This procedure is aimed at optimizing the movements of the bar feeder axis. This procedure
should not be performed daily but rather occasionally (recommended time: once a month) to
compensate any wear of the mechanical feeding units that could alter the AXIS control
operations.
Procedure:
Move the feeding carriage from its completely backwards
position in manual mode
, then simultaneously
press
and for at least two seconds, until
Offset appears on the display. Now the operator may
release the keys.
INFORMATION:
Before performing the following procedure
make sure that the mechanics have no
clearances (e.g.: feeding chain not tensioned properly) and that the zero axis
sensor is positioned correctly (make sure it is not too retracted).
Offset...
