IEMCA Smart 320 Tp - 5.3.3 BAR PUSHER REPLACEMENT PROCEDURE

5 - ADJUSTMENT AND SETUP SMART320
EN
5 - Pag. 15 / 20
5.3.3 BAR PUSHER REPLACEMENT PROCEDURE
WARNING - CAUTION
Do not absolutely perform the following procedure with a bar in the bar pusher
collet!
The replacement of the bar pusher, for a working cycle change or maintenance, may be
performed as follows:
- bring the bar pusher in manual mode
, with close guide channels;
- if the upper guide channel is open press
;
- press and hold down
to start the automatic procedure which allows the bar feeder to
move to the appropriate condition for the bar pusher replacement.
by pressing
, the bar pusher is positioned past the clamp device and the guide channels
open;
- remove the bar pusher
INFORMATION
If during the abovementioned operations
is released, the procedure will
stop. By pressing the button again, the procedure will start from where it had
stopped.
NEW BAR PUSHER INTRODUCTION
- Assemble a new bar pusher and press
- Bring the bar pusher to zero axis position.
WARNING - CAUTION
Check if the bar pusher has been correctly introduced into the first feeding
carriage housing.
On the contrary, proceed to zero axis sensor adjustment.
