IEMCA Smart 320 Tp - 11.12 EJECTORS 602 P..011; 11.13 EJECTORS Œ Guide channels ø13÷23 - Table

11 - COLLETS SMART320
EN
11 - Pag. 15 / 18
11.12 EJECTORS 602P..011
11.13 EJECTORS – Guide channels ø13÷23 - Table
WARNING – CAUTION:
the external diameter of the ejector must be at least 0.5 mm less than the
external diameter of the bar pusher.
INFORMATION:
upon specific request, non standard collets with reduced thickness (which are
not mentioned in this table) may be supplied as well. Their durability is however
below the durability of standard collets.
A Ejector
