11 - COLLETS SMART320
11 - Pag. 14 / 18
S square bars (S=E/1,414) S hexagonal bars (S=E/1,154)
MIN MAX MIN MAX
External diameter
(mm)
øD
Diameter (mm)
øF
3 3 3 4 7,5 M5x0,5
4 6 5 7 12 Ø8 G6
6 10 6 13 18 Ø11 G6
7 12 * 5/16” 15 21 Ø14 G6
WARNING: the values indicated with * are expressed in inches.
