2.9 DEVICES FOR CAM LATHES - FOREWORD
This feeder has been designed and manufactured to be coupled to cam lathes too. To do this,
special devices are available which are listed and then described below.
2.9.1 Cam box - Description
Used to synchronize the feeder and cam lathe
movements. The cams located in the box (A) are
connected to the lathe camshaft (B).
