2 - TECHNICAL INFORMATION SMART320
2 - Pag. 18 / 20
2.8.2 Telescopic nose - Description
It is used to optimize bar guiding between the
bush holder device and the lathe spindle.
Maximum stroke and overall dimension
Model
Maximum stroke
A (mm)
Overall dimensions
B (mm)
120 230
160 320
170 200
220 260
SMART 320
320 310
IDM - 30215401700
A
B
