IEMCA Smart 320 Tp - 2.3 SAFETY DEVICES

2 - TECHNICAL INFORMATION SMART320
EN
2 - Pag. 7 / 20
2.3 SAFETY DEVICES
A EMERGENCY BUTTON; when pressed, all bar feeder and lathe functions are stopped in an
emergency condition.
C INTERLOCKED SLIDING GUARD: linked to microswitch C1.
according to the cycle setting, its functions are:
manual cycle;
- when the guard is opened, the feeder will be stopped if the guide channels are not
closed.
- when the guard is opened, if the guide channels are closed, the feeder functions are not
disabled because no risks for the operator are present.
- automatic cycle;
- during the bar feeding phase guard opening may be necessary for the purpose of
restocking the magazine. Even if the feeder functions are not disabled, there are no
operator hazards present inside the area.
- during the bar change procedure, the feeder will stop when the guard is opened. The
guard closing allows the user to start the cycle again.
