IEMCA Smart 320 Tp - 11.10 BORING COLLETS FOR BARS 601 P; 11.11 BORING COLLETS FOR SQUARE AND HEXAGONAL BARS - Table

11 - COLLETS SMART320
EN
11 - Pag. 13 / 18
11.10 BORING COLLETS FOR BARS 601P
11.11 BORING COLLETS FOR SQUARE AND HEXAGONAL BARS - Table
INFORMATION:
to determine the internal diameter øA do not refer to “001 - Conversion Tables”,
but refer directly to the table below.
INFORMATION:
upon specific request, non standard collets with reduced thickness (which are
not mentioned in this table) may be supplied as well. Their durability is however
below the durability of standard collets.
Code structure
A Collet
B Bar diameter
C Example:
3 mm = 030
3.5 mm = 035
12.5 mm = 125
12.75 mm = 127
D Category
