EN
4 - HANDLING AND INSTALLATION SMART320
4 - Pag. 8 / 26
• Roughly adjust the height of the working axis
and the alignment with the lathe by turning the
screws of the support feed.
4.4.4 Sleeve - Installation
• Install the sleeve (A) on the front plate.
• Install the oil recovery tank (B).
• Connect the drain pipe (C) to the tank.
