11 - COLLETS SMART320
EN
11 - Pag. 9 / 18
11.6 COLLET FOR 011 BARS
11.7 COLLET FOR BARS - Table
WARNING – CAUTION:
the collet external diameter should be at least 0.5 mm smaller than the bar
pusher external diameter.
INFORMATION:
upon specific request, non standard collets with reduced thickness (which are
not mentioned in this table) may be supplied as well. Their durability is however
below the durability of standard collets.
Code structure
CH*: double-ended fork wrench DIN3110
A Collet
B Bar diameter
C Example:
0.8 mm = 008
3 mm = 030
12.25 mm = 122
12.5 mm = 125
D Category
