6 - USE AND OPERATION SMART320
EN
6 - Pag. 15 / 22
6.5.3 Automatic cycle start
• Power the lathe on.
• Turn the main switch to position I (ON).
• Press
to start the bar feeder.
• Press
, to select the manual mode.
• If the bar pusher has been moved while power
supply was disconnected, the bar feeder zero
setting should be performed when turning the
machine on again, as follows:
• with upper guide channels closed or open,
press
IF THE BAR-PUSHER HAS NOT BEEN MOVED
WHILE POWER SUPPLY WAS DISCONNECTED, “ZERO AXIS” CONTROL HAS NOT TO BE
PERFORMED WHEN POWERING THE MACHINE AGAIN.
After carrying out the above-mentioned operations, perform next step:
• Enter the parameter values (refer to the "Keyboard Instruction Manual" ).
• Press the manual feed button to bring the bar fore end near the cutting tool.
To start machining, press
, when the lathe collet is closed. From now on, you will
obtain automatic bar feeding until bars are ended or according to the set program.
• During machining, empty the remnant recovery box. Remove the box after lifting it over the
tank edge.
WARNING – CAUTION:
do not manually lift loads with weights exceeding those foreseen by the
applicable regulations in force.
