IEMCA Smart 320 Tp - 2.5 VERSION DESCRIPTION

EN
2 - TECHNICAL INFORMATION SMART320
2 - Pag. 10 / 20
2.5 VERSION DESCRIPTION
Maximum and minimum bar length
Model Version
Maximum length
mm (ft)
Minimum length
mm (ft)
32 3260 (10,7) 1500 (4,9)
SMART 320
40 4060 (13,3) 1500 (4,9)
Maximum bar pusher extension
Model Version Version
A – Maximum
extension (mm)
L 1030
SMART 320 32 - 40
LL 1430
A18_MUM_02_05_00
B
A
C
B - Revolving tip
C - Nipple
