5 - ADJUSTMENT AND SETUP SMART320
5 - Pag. 4 / 20
5.3 SET-UP ACCORDING TO THE BAR TO BE MACHINED
According to the "new" diameter of the bar to be machined, a few or several operations must be
carried out based on the diameter of the previously machined bar.
The table “SMART 320 V-shaped bush diameter” shows the max. and min. suitable diameters for
the correct operation of the bushes. The table “SMART 320 guide channel, bar pusher, bar and
pipe diameters” shows the available guide channel diameters with the corresponding range of
bar pushers to be mounted and the range of diameters of the bars to be machined.
Bush adjustment according to the bar to be machined
Diameters of V-shaped bushes for SMART 320
MODEL BAR DIAMETER
BUSH
TYPE
MIN MAX
3 16 V
SMART
320
8 20 V
For shaped bars (e.g. square or hexagonal), the bush holder device should be disabled.
