EN
2 - TECHNICAL INFORMATION SMART320
2 - Pag. 6 / 20
When the first feeding carriage (M) completes its
stroke, the required space has been created for
bar pusher insertion.
The first feeding carriage performs the return
stroke.
The upper guides (H) are closed; the bar-pusher
(A) is positioned along the spindle axis. The bar
selection device (F) is lowered allowing the bars
to rest on the upper guide holder.
The clamps (D) close, the bar pusher (A) moves
forwards; the bar (G) is inserted into the bar
pusher collet.
The bar pusher (A) and bar (G) perform their
facing stroke. A new automatic working cycle is
started.
