4 - HANDLING AND INSTALLATION SMART320
4 - Pag. 4 / 26
LIFTING WITH NO PACKAGING
• Insert the four eyebolts into the external
plates of the bar feeder foot, in the
positions shown in the picture.
• Use a hook type lifting device of suitable
capacity.
• Use lifting belts of suitable capacity.
• Use lifting belts of suitable length so that
the angle between them is not greater
than 60°.
LIFTING WITH PALLET
• Use a hook (or fork) type lifting device of
suitable capacity (see information on
packaging).
LIFTING WITH CRATE
• Use a hook (or fork) type lifting device of
suitable capacity (see information on
packaging).
DANGER - WARNING:
never use any lifting systems or
devices different from the ones above.
