EN
5 - ADJUSTMENT AND SETUP SMART320
5 - Pag. 8 / 20
Three types of first feeding flag are available:
one for diameters from 8 to 11mm, the second
for diameters from 13 to 17mm and the third for
diameters from 21 to 24 mm.
Replacement should be carried out as follows:
• bring the first feeding flag to its back limit
stop and loosen both fixing screws (A).
• Now remove and replace the lower guide
channels.
• Do not replace or adjust the upper guide
channels even if the bar pusher diameter is
different.
