HD2 Series Inverter Dimension Drawings
-378-
Figure C-17 Parallel mounting diagram for 380V 710–3000kW and 660V 800–3000kW
Table C–5 Dimensions of closely mounting parallel 380V inverters (Unit: mm)
Inverter
model
W1
W2
W3
W4
H1
H2
D1
D2
D3
Mounting
hole
560–630kW
1447
1383
1417
13
1419.9
1356
442.5
429.5
350
Ø12
710–1000kW
1323
1253
1288
13
1900
-
636.3
625.5
570
Ø12
1200–1500kW
1956
1886
1921
13
1900
-
636.3
625.5
570
Ø12
2000kW
2589
2519
2554
13
1900
-
636.3
625.5
570
Ø12
2500kW
3222
3152
3187
13
1900
-
636.3
625.5
570
Ø12
3000kW
3855
3785
3820
13
1900
-
636.3
625.5
570
Ø12
Table C–6 Dimensions of closely mounting parallel 660V inverters (Unit: mm)
Inverter
model
W1
W2
W3
W4
H1
H2
D1
D2
D3
Mounting
hole
710kW
1447
1383
1417
13
1419.9
1356
442.5
429.5
350
Ø 12
800–1200kW
1323
1253
1288
13
1900
-
636.3
625.5
570
Ø 12
1500kW
1956
1886
1921
13
1900
-
636.3
625.5
570
Ø 12
2000–
2500kW
2589
2519
2554
13
1900
-
636.3
625.5
570
Ø 12
3000kW
3222
3152
3187
13
1900
-
636.3
625.5
570
Ø 12
