Chapter 5 Relay Ladder Logic Programming 97
-
Example 3:
Example 4:
RTC Mode 3 (Yea r-Month-Day)
The Year-Month-Day Mode 3 allows the RTC coil acting based on Year, Month, and Date. The
configuration dialog below (example 1) allows setting the workday between two different dates.
If the year is set as 00-00, the particular mode is available. The RTC is ON from the start date to the end
date every year. More refer to example 4.
①
②
③
RTC Mode 3, Year-Month-Day
④
Display RTC present time, Year-Month-Day
⑤
⑥
⑦
⑧
⑨
RTC code (R01~R1F, total 31 group)
