IS620P User Manual Chapter 7 Function Code Table
- 211 -
No.
Function
Symbol
Function
Name
Description Remarks
FunIN.15 N-OT
Reverse
overtravel
switch
When the mechanical
movement is outside
the movable range, the
overtravel prevention
function is implemented.
Valid: Reverse drive
forbidden
Invalid: Reverse drive
allowed
It is recommended
that the logic of the
corresponding terminal
be set to level valid.
FunIN.16 P-CL
External
forward
torque limit
The torque limit source is
switched over based on the
setting of H07-07.
H07-07 = 1:
Valid: External forward
torque limit enabled
Invalid: Internal forward
torque limit enabled
H07-07 = 3 and AI limit
larger than external forward
limit:
Valid: External forward
torque limit enabled
Invalid: AI torque limit
enabled
H07-07 = 4:
Valid: AI torque limit
enabled
Invalid: Internal forward
torque limit valid
It is recommended
that the logic of the
corresponding terminal
be set to level valid.
FunIN.17 N-CL
External
reverse
torque limit
The torque limit source is
switched over based on the
setting of H07-07.
H07-07 = 1:
Valid: External reverse
torque limit enabled
Invalid: Internal reverse
torque limit enabled
H07-07 = 3 and AI limit
smaller than external
reverse limit:
Valid: External reverse
torque limit enabled
Invalid: AI torque limit
enabled
H07-07 = 4:
Valid: AI torque limit
enabled
Invalid: Internal reverse
torque limit valid
It is recommended
that the logic of the
corresponding terminal
be set to level valid.
