Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
124 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
Remarks: This command affects the complete print image, including text,
bar codes, graphics, lines, and boxes, as well as the location f the
reference point, see “R - Set Reference Point” on page 104.
A label printed using the command ZT.
A label printed using the command ZB.
Example:
This example makes the printer print from the bottom of the
image, see command below.
ZB 
Note: that printing a test label in the Test modes or using a U or
UP command resets the print direction to default (ZT).
EASYCODER PC4
Feed Direction
EASYCODER PC4
Feed Direction

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
