Intermec EasyCoder PC4 Programmer's Reference Manual

Chapter 7 — Commands
ESim for the PC4 and PF8 Printer Programmer’s Reference Manual 129
Command must end with <CR> or <LF> to be correctly
executed.
The printer replies to the host via serial port in one of the
following formats:
1 If no error code is available (normal case):
00<CR><LF>
00 = Status code OK
2 If only one error code is available:
XX<CR><LF>
XX = Error or status code
3 If more error or status codes are available:
XX,YY,ZZ..<CR><LF>
XX YY ZZ.. = Error or status codes.
An ^ee command cannot be performed:
• during downloading of images, fonts, or forms.
• inside a variable input (?), or inside a string area (“”).
• when the input data buffer is full (> 8000 bytes).
At position error-waiting-recovering, the command ^ee must be
sent into the printer via the RS-232 or USB interface to get an
error report.
Note: An error report has higher priority than other commands
and is processed directly, both in position of normal command
input and in position of any error recovery.

Intermec EasyCoder PC4 Specifications

General

Resolution	203 dpi
Power Requirements	100-240 VAC, 50-60 Hz
Print Method	Direct Thermal
Max Print Width	4.09 inches (104 mm)
Max Print Speed	4 inches per second
Max Print Length	39 inches
Media Type	Roll-fed, die-cut, continuous, fanfold, tags, tickets
Media Width	1.0 - 4.65 inches
Media Thickness	0.06 mm (0.00236 in) to 0.18 mm (0.00708 in)
Interface	RS-232
Memory	4 MB Flash, 8 MB SDRAM
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Humidity	10 to 90% non-condensing
