Chapter 7 — Commands
38 ESim for the PC4 and PF8 Printer Programmer’s Reference Manual
Example:
N
A50,0,0,1,1,1,N,“Example 1”
A50,50,0,2,1,1,N,“Example 2”
A50,100,0,3,1,1,N,“Example 3”
A50,150,0,4,1,1,N,“Example 4”
A50,200,0,5,1,1,N,“EXAMPLE 5”
A50,300,0,3,2,2,R,“Example 6”
P1
p
5
Horizontal multiplier 1, 2, 3, 4, 5, 6, 7, 8
p
6
Vertical multiplier 1, 2, 3, 4, 5, 6, 7, 8, 9
p
7
N = Normal image
R = Reverse image
“DATA” Represents a fixed data field.
When using Asian double-byte fonts, specify both bytes as ASCII decimal
values, starting with the first value being larger than ASCII 127 decimal
(ASCII 7F hex), or below ASCII 127 (ASCII 7F hex) decimal to specify a
Latin character.
A Command Parameter Descriptions (continued)
Parameter Description
Note: Font size 5 only supports uppercase characters, see example
5 in the label above.
