11.13. Annex 13: Configuration List

Check Qty Description/Item List

Radar Field Analyser

O 1 Radar Field Analyser - RFA641

O 1 3.5GHz option

O 1 Mains power cable

O 1 USB cable A to B - 3m

RFA Accessories

O 1 Log Periodic Antenna 900-3300MHz; LPA114

O 1 Antenna tripod Vanguard Mk-2

O 1 Antenna cable: MCX(m) to BNC(m) RG316 - 1m

O 1 BNC(m) to BNC(m) RG223 - 4m black

O 1 BNC(m) to BNC(m) RG223 - 0.5m black

O 1 BNC(m) to BNC(m) RG223 - 0.16m black

O 1 BNC(m) to BNC(m) RG223 - 0.16m white

O 1 15pHD to 5 BNC(m) cable - 1.8m

O 1 Monitor output Cable: DB9(m) to BNC(m) RG316 - 2m green

O 1 BNC(f) straight adaptor DC-4GHz

O 2 Attenuator 10dB BNC DC-4GHz 50ohm

O 2 Attenuator 20dB BNC DC-4GHz 50ohm

O 1 Directional coupler ZFDC-10-5 BNC

O 1 DC/AC Inverter 12V->115V

O 1 IEC-320 Extension Lead Socket-Plug

O 1 DIN-4165 socket to battery clamps
