Radar Field Analyser - RFA641 Edition Date: 28-Feb-18
Different test scenarios can be generated, (according to RTCA DO260/260A ) with different levels of
interference signal load, level, power, position in squitter reply, etc… In each of these cases, a different
detection level is to be expected.
9.2. Key Specifications
9.2.1. General Specifications
• Max nr of targets : 2048 but limited by sequential nature of ADS-B replies, max. 7500 replies can be
generated per second
• Max number of replies 3978 / second
• Nr of independent target generators: 1
• Max nr of overlapping Targets (garbling simulation): 1
• FRUIT generation with 2nd RFA: Up to 22000 Fruits/sec ( not simultaneous with ADSB)
• ProgrammableFixed target frequency : 1090 Mhz.
• Target power output: +15..-45dBm at RFA output-30..-90 dBm at ADSB Rx input
• -25..-85 dBm at sensor input
• Full simulation of Horizontal and Vertical Mono-pulse SSR Antenna or ADSB Omni- antenna diagram
• Path Loss simulation with Aircraft antenna modelling
9.2.2. Target Types
• Transponders programmable squitter rates for Airborne/Ground velocity, position and ID squitters.
• Supports DF 11, DF17 and DF18 squitters
• Transponder power programmable
• ICAO Annex 10 am 77 compliant Transponders logic and RF signals
• RTCA DO-260A compliant squitter reports
9.2.3. Scenario
• Simulation of straight flights, turns, accelerations, climbs, descends, static targets, accelerated turns,
etc…
• Programmable rates for Velocity, Position and ID reporting in squitters.
• Programmable S address per target
• Programmable TYPE and Subtype values, linked with NIC and Rc
• In flight Code changes, Emergency codes, SPI, etc …
• Programmable Status message squitters
• Automatic Generation of load models and other example scenarios
• Simulation of sensor output data (ASTERIX cat 21 )
9.2.4. Recording
(requires additional hardware)
• Using UTC time-stamping (GPS)
• Recording of serial radar data(RDR803 or UDR600)
• Recording of LAN radar data (UDP-IP or TCP-IP) through host-PC LAN port
• Recording of generated video signals (RIM782)
9.2.5. Analysis
• Analysis of Accuracy, Resolution behavior, Pd, Sensitivity
• Automatic comparison
• Visualization of Video data
