• After loading new firmware or clearing the receiver's NVRAM, the
receiver checks its internal file system.
During this operation, the REC LED flas
hes orange
, and the file system
is not accessible for CDU (control display unit) applications or for data
recording. This operation may require from fractions of a second to
several minutes, depending on the circumstances and the amount of
internal memory.
Table 4-1. FN Key Functions and REC LED Status
FN Key REC LED Status
When data recording is OFF, and the FN key is...
Not pressed
No light No data recording.
Orange blink Internal file system test in progress.
Red
No free memory; hardware problem with
d
ata r
ecording.
Pressed for < 1 second
If FN key mode is «LED blink mode switch»
Orange Rele
ase to charge information mode.
If FN key mode is «Occupation mode switch»
Orange No function.
Pressed for 1–5
seconds
If FN key mode is «LED blink mode switch»
Green
Release to start data recording (post-
p
rocessing occupation mode und
efined).
If FN key mode is «Occupation mode switch»
Green
Release to start recording (Kinematic or
Static post-processing occupation
mode).
Pressed for 5–8
seconds
Red
Release to turn serial port A baud rate to
9600 bps.
Pressed fo
r > 8
seconds
No light No function.
