www.javad.com Maxor Operator’s Manual 3-1
SETUP AND MEASURING 3
This chapter describes the following:
Maxor Receiver Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-2
Measuring wit
h the Maxor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Chapter Tip:
To set up your Maxor receiver, you must:
1. Configure the receiver as described in “Configuration”.
2. Set up your Base or Rover station. See “Step 1” on page 3-2.
3. Measure the antenna height. See «“Step 2” on page 3-2 for internal
antennas, or see “External Antenna Setup” on page 3-4 for external
antennas.
4. Begin collecting data. See “Step 3” on page 3-4.
All Maxor receivers include an internal, micro-strip an
tenna. This antenna is
able to capture L1/L2 signals from GPS and GLONASS satellites. Also, your
Maxor can be used with an optional external antenna.
