2-10 Maxor Operator’s Manual www.javad.com
CONFIGURATION
Connecting the Maxor and a Computer
2
3. Once the Master device detects the receiver, use the procedure
described in the external device’s documentation to connect it with the
receiver.
4. Once connected, continue with Step 1 in “Establishing a PCView
Connection” on page 2-11.
If you cannot establish a connection, check that the recei
ver’s
slot three is
enabled.
1. Connect your receiver and a computer using
an RS232 cable (see
“Establishing an RS232 Cable Connection” ).
2. Start PCView.
3. Click C
onfiguration->Receiver->General.
4. In the Turn on/off Slots area, ensure the Slot 3 (B) check box is
enabled.
Establishing an RS232 Cable Connection
1. Using the RS232 cable, connect the serial port of your computer
(usually COM1) to the receiver’s serial port A.
2. Press the po
wer buttons on the rece
iver and computer to turn them on.
3. Continue with Step 1 in “Establishing a PCView Connection” on
page 2-11
.
Establishing a USB Cable Connection
Make sure the computer has JNS’s USB driver installed (available from
Support area Free Software section of http://www.javad.com) before
continuing.
1. Using the USB cable, connect the USB port on
the receiver to a USB
port on the computer.
2. Press the power buttons on the receiver an
d computer to turn them on.
3. Continue with Step 1 in “Establishing a PCView Connection” on
page 2-11.
