www.javad.com Maxor Operator’s Manual 2-7
CONFIGURATION
Powering the Maxor
• Battery B – displays the voltage of battery B.
• Charger – disp
lays the charger’s output voltage during battery
charging.
• On P
orts – disp
lays the voltage output on pin one of all serial ports
connectors.
9. Select and check each of the Turn
on/off Slots check boxes to enable
the corresponding internal slots (Figure 2-7).
Figure 2-7. Enable Slots
10. Select and check the Enable Low Power Mode check box to put the
receiver’s processor into low power consumption mode (Figure 2-8).
Figure 2-8. Activate Low Power Mode
11. Click Apply.
