4-6 Maxor Operator’s Manual www.javad.com
OPERATION
Using MinPad
4
• Solid light – an external power supply is used and the batteries are not
being charged.
• Blinking once a second – the batteries are being charged.
• Blinking once every five seconds – the Maxor uses the internal batteries
for po
wer.
• N
ot blinking – the receiver is in Zero Power Mode or the internal
batteries
are completely discharged and no external power is connected.
Notice: When the internal batteries have completely discharged
and no external power is connected, the receiver will go
into Zero Power Mode to prevent the batteries from over
discharging.
RX LED
Your Maxor receiver may be equipped with a different modem type, e.g.
with PDL from Pacific Crest or with JNS 2W UHF 410-470 radio
transceiver, or with single GSM/GPRS radio modem. The color of the RX
LED indicates if the modem has power, is receiving signals, or is turned off.
The RX LED shows status of the modem’s operation.
JNS 2W UHF 410-470 radio transceiver
• No light – the modem is turned off.
• Solid green – the modem is in waiting mode
• Solid green + red flashes – the modem is receiving data
• Solid red – the modem is transmitting data
• Red flas
hes + green flashes – the modem is in command mode.
PDL Modem
• No light – the modem is turned off.
• Green – the modem is on, but signal reception has not started.
• Orange – the modem is receiving a signal.
Single GSM/GPRS radio modem
• No light – the modem is turned off.
• Solid orange – Modem is not registered in network.
