SETUP AND MEASURING
Maxor Receiver Setup
3
Maxor Receiver Setup
Follow steps 1 through 3 to setup your receiver.
Step 1
Set up Receiver
This section assumes you have already configured your receiver using
PCView.
1. Place the Maxor on the appropriate tripod or bipod.
2. Center the receiver over the point at which data will be collected. For
most applications, this should be at a location with a clear view of the
sky.
Step 2
Measure Antenna Height
The location of the antenna relative to the point being measured is very
important for both surveys in which the elevation of the points is important
and in surveys for horizontal location only. Horizontal surveys are often
larger in area than can reliably fit on a flat plane, therefore the antenna
adjustment must be done in three dimensions and then projected onto a two
dimensional plane.
The receiver calculates the coordinates of the antenna's phase center. To
determine the coordinat
es of the station
marker, the user must specify the
following:
• Measured height of the antenna above the sta
tion marker
• Method of measuring the antenna height
• Model of the antenna used
Antennas have two types of measurements:
• Ve
rti ca l – measured from the marker to the a
ntenna reference point
(ARP) located on the bottom of the receiver at the base of the mounting
threads.
• Slant – measured from the marker to the lowe
r edge of the antenna slant
height measure mark (SHMM) located on both end panels of the
receiver.
