B-2 Maxor Operator’s Manual www.javad.com
APPENDIX
Receiver Specifications
B
Receiver Specifications
The following sections provide specifications for the receiver and its internal
components.
General Details
Table B-1 table lists the receiver’s general specifications.
Table B-1.
Receiver General Specifications
Physical
Enclosure Aluminum extrusion, rainproof
Color JNS Green and Gray
Dimensions
Maxor GG/GD/ GGD W:159 x H: 90 x D:175 mm
Maxor GGDT W:159 x H: 115 x D:162 mm
Weight
Maxor GG/GD/ GGD 1.6 kg
Maxor GGDT 1.620 kg (1.760 kg with UHF modem)
Antenna Internal
Battery Two internal
Controller External
Mounting 5/8-11
Seals Silicon (molding in Color)
Keys
Three keys:
Power – On/Off
Function (FN) – start/stop data logging; switch information mode.
R
eset – receiver hardware reset
LEDs
Four LEDs:
STAT – satellite and receiver status
REC – record and data status
BATT – battery status
RX – modem status
Environment
Operating
temperature
-30 C° to + 50 C° (TBD) with batteries
