www.javad.com Maxor Operator’s Manual B-3
APPENDIX
Receiver Specifications
Storage
temperature
-20 C° to +35 C° with batteries
Humidity 95% non-condensing
Power
Internal battery Li-Ion, 3000 mAh, 7.4 V
Battery size 132 x 35 x 18 (mm)
Battery weight 165 g (1 battery)
Number of built-in
batteries
2
batteries
Operating time
Maxor GGDT with JNS 2W UHF 4
10-470 radio transcei
ver
~10 hours with 1 W Transmit ON
~7 hours with 2 W Transmit ON
~16 hours with Receive ON
~13...~15 (by continuous call) hours with
GSM/GPRS (GSM 900) ON
~14...~15 (by continuo
us call) hours with GSM/GPRS (GSM 850) ON
~13...~15 (by continuous call) hours with GSM/GPRS (DCS 1800) ON
~13...~15 (by continuous call) hours with GSM/GPRS (PCS 1900) ON
W
ith Radio OFF
~ 18 hours
With UHF PDL Radio ON
~16 hours (Maxor-GD)
~12 hours (Maxor-GGD)
With UHF PDL Radio OFF
~18 hours (Maxor-GD)
~14 hours (Maxor-GGD)
Input voltage
6 to 28 V DC (for work)
9 to 28 V DC (for charge battery)
Minimum Charge Current >=2 Amp
Power
consumption
8.3 W with 2 W Transmitter ON
6 W with 1W Transmitter OFF
3.7 W with Receive ON
4 W...4.6 W (during a call) with
GSM/GPRS (GSM 900) ON
4
W...4.4 W (during a call) with GSM/GPRS (GSM 850) ON
4 W...4.5 W (during a call) with GSM/GPRS (DCS 1800) ON
4 W...4.6 W (during a call) with GSM/GPRS (PCS 1900) ON
3
.3 W with Radio OFF
Table B-1.
Receiver General Specifications (Continued)
