CONFIGURATION
Powering the Maxor
be able to supply sufficient current (2.5 Amp) to operate/charge the
receiver.
Warning:
Before connecting the external power source and the
receiver, make sure that the power source matches
the receiver’s voltage and current requirements.
Notice:
When the receiver uses an external battery as the primary
power source, make sure that the charger mode is set to
Off. Otherwise, the external battery will also charge the
internal batteries, causing operation time to decrease.
See “Power Management” on page 2-4 for more
information on setting the charger mode.
1. Connect the SAE ends of the battery clip-to-SAE and the SAE-to-
pow
er plug cables.
2. Plug the power cable into the receiver’s power port.
3. Attach the battery clip to the battery.
Battery Charger
The same charger used to charge the internal batteries can be used as an
external power supply for the receiver. The charger is provided with the
standard receiver package.
To use power from the battery charger, connect the equipment
as follows
(Figure 2-1 on page 2-4):
• Plug the Receiver-to-SAE cable’s 5-pin connector (p/n 14-008016-03)
into the power port of the rec
eiver (labeled PWR).
• Connect the opposite end of this cabl
e with the battery charger’
s SAE
connector.
• Plug the appropriate end of the power supply-to-outlet cable into the
battery charger.
•
Plug the other end of this cable into an AC outlet.
• Press and hold the Reset key
for about one second to ensure that the
receiver is in Normal mode for accepting power.
• Turn on the receiver by pressing and holding the green power key for
ab
out 0.5 seco
nds.
