JOHNSON CONTROLS
115
SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
TABLE 41 - STATUS
DISPLAY TEXT RANGE DEFAULT
SETTING
LOCATION
SHOWN WHEN
UNIT - OVERALL
STATUS
Local Stop / Run / Unit Trip / Unit Fault / Unit
Lockout / SMK Purge #-Press / SMK Purge #-Purge
/ SMK Purge #-Evac
Derived Always
CURRENT OPER
MODE
Occ Standby / Occ Cooling Low / Occ Cooling High
/ Occ Heating Low / Occ Heating High / Unocc
Standby / Unocc Cooling Low / Unocc Cooling
High / Unocc Heating Low / Unocc Heating High /
Morning Warm-Up / Comfort Vent Cooling / Comfort
Vent Heating
Derived
Unit Type
Equals CV
CURRENT OPER
MODE
Occupied Standby / Occupied Heating / Occupied
Cooling / Unoccupied Standby / Unoccupied
Heating / Unoccupied Cooling / Morning Warm-Up
Derived
Unit Type
Equals VAV
CURRENT OPER
MODE
Occupied Standby / Occupied Heating / Occ
Cooling Without Bypass / Occ Cooling With Bypass
/ Unoccupied Standby / Under Floor Temp Override
Derived
Unit Type Equals
FLEXSYS
SUPPLY SYS
STATUS
Normal - Active / Normal Inactive / Safety Trip /
Safety Fault / Safety Lockout
Derived Always
COMP SYS 1
STATUS
Normal - Comp A On / Normal - Comp B On /
Normal - Both On / Normal - Both Off / Safety Trip
/ Safety Fault / Safety Lockout / Low Amb Inhibit
/ Low Suct Temp Unl / High Dp Unload / User
Disabled
Derived Always
COMP SYS 2
STATUS
Normal - Comp A On / Normal - Comp B On /
Normal - Both On / Normal - Both Off / Safety Trip
/ Safety Fault / Safety Lockout / Low Amb Inhibit
/ Low Suct Temp Unl / High Dp Unload / User
Disabled
Derived Always
COMP SYS 3
STATUS
Normal - Comp A On / Normal - Comp B On /
Normal - Both On / Normal - Both Off / Safety Trip
/ Safety Fault / Safety Lockout / Low Amb Inhibit
/ Low Suct Temp Unl / High Dp Unload / User
Disabled
Derived Always
HEATING SYS
STATUS
Normal - Active / Normal - Inactive / Safety Trip /
Safety Fault / Safety Lockout / User Disabled / None
Derived Always
ECONO SYS
STATUS
Normal - Active / Normal - Inactive / Safety Trip /
Safety Fault / Safety Lockout / User Disabled / None
Derived Always
VENT SYS
STATUS
Normal - Active / Normal - Inactive / Safety Trip /
Safety Fault / Safety Lockout / User Disabled / None
Derived Always
EXHAUST SYS
STATUS
Normal - Active / Normal - Inactive / Safety Trip /
Safety Fault / Safety Lockout / User Disabled / None
Derived Always
SENSOR / MISC
STATUS
Normal / Warning / Safety Trip / Safety Fault /
Safety Lockout
Derived Always
FILTER STATUS Okay / Change Derived Always
