JOHNSON CONTROLS
20
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 2 – INSTALLATION
TABLE 3 - PHYSICAL DATA
70 TON MODELS
MODEL SIZE 070
General Data
Standard cabinet length without hoods
(inches)
454
Extended cabinet length without hoods
(inches)
517
Width (Inches) 92
Height (Inches) 92
Weights (Lbs.) (base unit, no option)
Base cabinet, cooling only with
economizer
11,817
Extended cabinet, cooling only with
economizer
13,027
Option Weights (Lbs.)
Power Exhaust (Blower, mtr, mtr base,
fan skid, mod damper & hood)
1045
Power Exhaust (Blower, mtr, mtr base,
fan skid, VFD,baro damper & hood)
1044
100% AMS
(Measurement Station & Mounting)
125
25/75% AMS
(Measurement Station & Mounting)
146
Min. AMS
(Measurement Station & Mounting)
45
Barometric only 45
375 MBH Gas Heat 162
750 MBH Gas Heat 324
1125 MBH Gas Heat 486
40 kW/480/3/60 2 Steps Electric Heat NA
80 kW/208/3/60 or 108 kW/240/3/60 6
Steps Electric Heat
NA
108 kW/480/3/60 3 steps Electric Heat 470
150 kW/480/3/60 4 Steps Electric Heat 490
200 kW/480/3/60 6 Steps Electric Heat 510
250 kW/480/3/60 7 Steps Electric Heat 530
Condenser Wire Guard 40
Copper Condenser Coils (additional) 617
Copper Evaporator Coils (additional) 280
Hot Water Coil 318
Steam Heating Coil 236
Diffuser
2
53
Final lters
2
535
Final lters, racks only
2
297
Roof Curb Weights (Lbs.)
14” Full Perimeter Roof Curb 1,020
14” Open Condenser Roof Curb 577
Compressor Data
Quantity/Size (Nominal HP) 6x10
Type Scroll
Capacity Steps (Qty x %) 6x16
MODEL SIZE 070
Refrigerant Charge (R410A STD Cabinet) *
SYS 1 - LB (KG) 44.3
SYS 2 - LB (KG) 38.5
SYS 3 - LB (KG) 42.4
Refrigerant Charge (R410A EXTD Cabinet) *
SYS 1 - LB (KG) 47.0
SYS 2 - LB (KG) 41.2
SYS 3 - LB (KG) 45.4
Refrigerant Charge (R410A STD Cabinet) w/ HGRH *
SYS 1 - LB (KG) 35.5
SYS 2 - LB (KG) 34.8
SYS 3 - LB (KG) 30.8
Refrigerant Charge (R410A EXTD Cabinet) w/ HGRH *
SYS 1 - LB (KG) 38.2
SYS 2 - LB (KG) 37.5
SYS 3 - LB (KG) 33.5
* Always verify proper charge values using the charge
information printed on the rating plate on the unit
Supply Fan and Drive
Quantity 1
Type FC
Size 28-25
Motor Size Range (min. to max. HP) 10–50
Air Flow Range (min. to max. CFM) 14000–29000
Static Pressure Range (min. to max. ESP) 0-4”
Optional Airfoil Supply Fan
Quantity 1 / 1
Type AF
Size 32
Motor Size Range (min. to max. HP) 15–50
Air Flow Range (min. to max. CFM) 14000–29000
Static Pressure Range (min. to max. ESP) 0-6”
Optional Direct Drive Plenum (DDP) Supply Fan
Quantity 1
Type DDP
Size 402-9-100/120
Motor Size Range (min. to max. HP) 10–75
Air Flow Range (min. to max. CFM) 14000–29000
Static Pressure Range (min. to max. ESP) 1–8”
Exhaust Fan
Quantity 2
Type FC
Size 18-18
Motor Size Range (min. to max. HP) 10–20
Air Flow Range (min. to max. CFM) 4000–32000
Static Pressure Range (min. to max. ESP) 0–2”
