JOHNSON CONTROLS
132
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 6 – USER INTERFACE CONTROL CENTER
TABLE 51 - SERVICE
DISPLAY TEXT TYPE ID VALUE RANGE LOCATION DESCRIPTION
DATA LOG FORMAT Off
Used To Activate The Data Log Feature
Of The Control
DATA LOG ERROR
Error
Detail
See Table 69 on
page 180
Data Log Error Detail
(Only Displayed When Error Is Present)
Error
State
See Table 68 on
page 180
Data Log Error State
(Only Displayed When Error Is Present)
UPDATE FLASH On / Off Used To Update Control Software
UPDATE FLASH
ERROR
Description Of The Error
(Only Displayed When Error Is Present)
FACTORY RUN TESTER
User Disable /
User Enable
Only Used For Factory Run Test
COMPRESSOR 1A
Digital
Output
TB4-2 On / Off I/O Board
Status Of The Digital Output To
Compressor 1A
COMPRESSOR 1B
Digital
Output
TB4-3 On / Off I/O Board
Status Of The Digital Output To
Compressor 1B
COMPRESSOR 2A
Digital
Output
TB4-4 On / Off I/O Board
Status Of The Digital Output To
Compressor 2A
COMPRESSOR 2B
Digital
Output
TB4-5 On / Off I/O Board
Status Of The Digital Output To
Compressor 2B
COMPRESSOR 3A
Digital
Output
TB4-7 On / Off I/O Board
Status Of The Digital Output To
Compressor 3A
COMPRESSOR 3B
Digital
Output
TB4-8 On / Off I/O Board
Status Of The Digital Output To
Compressor 3B
CONDENSER FAN 1A/1
Digital
Output
TB4-9 On / Off I/O Board
Status Of Digital Output To Condenser
Fan 1A
CONDENSER FAN 1B/2
Digital
Output
TB4-9 On / Off I/O Board
Status Of Digital Output To Condenser
Fan 1B
CONDENSER FAN 2A/3
Digital
Output
TB6-2 On / Off I/O Board
Status Of Digital Output To Condenser
Fan 2A
CONDENSER FAN 2B/4
Digital
Output
TB6-2 On / Off I/O Board
Status Of Digital Output To Condenser
Fan 2B
CONDENSER FAN 3A/5
Digital
Output
TB6-4 On / Off I/O Board
Status Of Digital Output To Condenser
Fan 3A
CONDENSER FAN 3B/6
Digital
Output
TB6-4 On / Off I/O Board
Status Of Digital Output To Condenser
Fan 3B
ELECTRIC HEAT STG 1
Digital
Output
TB3-2 On / Off I/O Board
Status Of Electric Heat Digital Output To
Stage 1
ELECTRIC HEAT STG 2
Digital
Output
TB3-3 On / Off I/O Board
Status Of Electric Heat Digital Output To
Stage 2
ELECTRIC HEAT STG 3
Digital
Output
TB3-4 On / Off I/O Board
Status Of Electric Heat Digital Output To
Stage 3
ELECTRIC HEAT STG 4
Digital
Output
TB3-5 On / Off I/O Board
Status Of Electric Heat Digital Output To
Stage 4
ELECTRIC HEAT STG 5
Digital
Output
TB3-7 On / Off I/O Board
Status Of Electric Heat Digital Output To
Stage 5
ELECTRIC HEAT STG 6
Digital
Output
TB3-8 On / Off I/O Board
Status Of Electric Heat Digital Output To
Stage 6
ELECTRIC HEAT STG 7
Digital
Output
TB3-9 On / Off I/O Board
Status Of Electric Heat Digital Output To
Stage 7
To Next Page
