JOHNSON CONTROLS
27
SECTION 2 – INSTALLATION
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
2
TABLE 6 - MISCELLANEOUS ELECTRICAL DATA
DESCRIPTION
NOMINAL VOLTAGE
208V 230V 460V 575V 380V
AMPS AMPS AMPS AMPS AMPS
Control Transformer 750 VA 3.6 3.3 1.6 1.3 2.0
Control Transformer 1.0 KVA 4.8 4.4 2.2 1.8 2.6
Convenience Outlet 9.6 8.7 4.4 3.5 NA
Gas Heat 9.6 8.7 4.4 3.5 5.3
TABLE 7 - COMPRESSOR DATA (R-410A)
MODEL
COMPRESSOR NOMINAL VOLTAGE
QUANTITY MODEL
208/230V 460V 575V
RLA LRA RLA LRA RLA LRA
070 6 ZP120 33.3 239 17.9 125 12.8 80
075
2 ZP154 51.3 300 23.1 150 19.9 109
4 ZP137 48.1 245 18.6 125 14.7 100
080
4 ZP154 51.3 300 23.1 150 19.9 109
2 ZP137 48.1 245 18.6 125 14.7 100
090
4 ZP182 55.8 340 26.9 173 23.7 132
2 ZP154 51.3 300 23.1 150 19.9 109
105
3 ZP182 — — 26.9 173 23.7 132
3 ZP235 — — 30.8 229 25.0 180
NOTE: RLA data is per compressor.
TABLE 8 - ELECTRIC HEAT AMP DRAW
kW*
NOMINAL VOLTAGE
208/3/60 230/3/60 460/3/60 575/3/60
AMPS AMPS AMPS AMPS
80 193 193 96 80
108 260 260 130 109
150 — — 181 151
200 — — 241 201
250 — — 301 251
*NOTE: Heaters are sized as follows:
• 208V heaters are rated at 208V
• 230V heaters are rated at 240V
• 460V heaters are rated at 480V
• 575V heaters are rated at 600V
TABLE 9 - AIRFLOW AND ENTERING AIR/AMBIENT LIMITATIONS
Limitations
Model Size
70 75 80 90 105
Minimum Airow at Standard Design
Conditions. CFM* (min to max)
14,000–
32,000
14,000–
32,000
14,000–
32,000
18,000–
36,000
20,000–
36,000
Entering Wet Bulb Temp (°F) (min/max) 57/75 57/75 57/75 57/75 57/75
Entering Dry Bulb Temp (°F) (min/max) 68/90 68/90 68/90 68/90 68/90
Ambient Temp (°F) without Low Amb option 50/120 50/120 50/120 50/120 50/120
Ambient Temp (°F) with Low Amb option 0/120 0/120 0/120 0/120 0/120
*NOTE: Cooling only units
