JOHNSON CONTROLS
116
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 6 – USER INTERFACE CONTROL CENTER
TABLE 42 - UNIT DATA
DISPLAY TEXT
PASS
WORD
LEVEL
RANGE DEFAULT
SETTING
LOCATION
SHOW WHEN UNIT
TYPE IS:
UNIT TYPE 2
Constant Volume / Variable
Air Volume / FlexSys /
Single Zone VAV
Constant Volume
Options /
Unit Data
Always
UNIT SIZE 2
70 Ton, 75 Ton, 80 Ton, 90
Ton, 105 Ton
50 Ton
Options /
Unit Data
Always
REFRIGERANT TYPE 2 R22 / R407c / R410a R-22
Options /
Unit Data
Always
CONTROL METHOD 1
Staged / Wired Zone Temp
/ Comm Zone Temp
Staged
Options /
Unit Data
Unit Type Equals
Constant Volume
SAT RESET METHOD 1
Hardwired, Outside Air,
Return Air, Supply Fan
Speed
Hardwired Input
Options /
Unit Data
Unit Type Equals Variable
Air Volum
SUPPLY AIR TEMP
CURRENT -20.0°FF To 180.0°F Look Up Table Unit Type E Equals
Constant Volume Or
Variable Air Volum
ACTIVE SP 50.0°F To 150.0°F Derived
MX SUPPLY AIR TEMP
CURRENT -20.0°F To 180.0°F Look Up Table
Unit Type E Equals
FlexSys
SETPOINT 1 50.0°F To 65.0°F 65.0°F
Setoints/
Unit Data
ZONE TEMP*
CURRENT -20.0°F To 180.0°F Look Up Table
Unit Type Equals
Constant Volume Or
Variable Air Volum
OCC ZONE COOLING
SETPOINT
1
OCC Zone Heating
Setpoint + 2.0°F
72.0°F
Setoints/
Unit Data
ZONE TEMP*
CURRENT -20.0°F To 180.0°F Look Up Table
Unit Type Equals
Constant Volume Or
Variable Air Volum
UNOCC ZONE
COOLING
SETPOINT
1
Unocc Zone Heating
Setpoint + 2.0°F To 95.0°F
85.0°F
Setoints/
Unit Data
ZONE TEMP*
CURRENT -20.0°F To 180.0°F Look Up Table
Unit Type Equals
Constant Volume Or
Variable Air Volum
OCC ZONE HEATING
SETPOINT
1
60°F To OCC Zone
Cooling Setpoint - 2.0°F
68.0°F
Setoints/
Unit Data
ZONE TEMP*
CURRENT -20.0°F To 180.0°F Look Up Table
Unit Type Equals
Constant Volume Or
Variable Air Volum
UNOCC ZONE
HEATING
SETPOINT
1
50.0°FF To Unocc Zone
Cooling Setpoint - 2.0°F
60.0°F
Setoints/
Unit Data
SMOKE PURGE
SEQ 1
1
Purge / Pressurization /
Evacuation
Purge
Options /
Unit Data
Always
SMOKE PURGE
SEQ 2
1
Purge / Pressurization /
Evacuation
Pressurization
Options /
Unit Data
Always
SMOKE PURGE
SEQ 3
1
Purge / Pressurization /
Evacuation
Evacuation
Options /
Unit Data
Always
DISPLAY LANGUAGE 1 English / Spanish English
Options /
Unit Data
Always
DISPLAY UNITS 1 Imperial / Metric Imperial Always
* Only the zone temp screen for the current active mode is shown.
