Page #17 background imageLoading...
Page #17 background image
JOHNSON CONTROLS
17
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
2
SECTION 2 – INSTALLATION
APPROVALS
Designed certified by ETL and CETL as follows:
1. For use as a forced air furnace with cooling unit
(gas heat models).
2. For outdoor installation only.
3. For installation on combustible material and may
be installed directly on combustible ooring or
Class A, Class B, or Class C roof covering materi-
als.
4. For use with natural gas or LP (propane) gas.
5. When used with LP gas, one of the following con-
version kits must be installed before the gas heat
section is red:
a. 375,000 BTU input - P/N 385-01866-001
b. 750,000 BTU input - P/N 385-01866-002
c. 1,125,000 BTU input - P/N 385-01866-003
Not suitable for use with conventional venting systems.
LIMITATIONS
The installation of this unit must conform to local
building codes, or in the absence of local codes, with
ANSI 223.1 Natural Fuel Gas Code and /or CAN/CGA
B149 installation codes.
In U.S.A.:
1. National Electrical Code ANSI/NFPA No. 70 -
Latest Edition.
2. National Fuel Gas Code Z223.1 - Latest Edition.
3. Gas-Fired Central Furnace Standard ANSI Z21.47
- Latest Edition.
4. Local gas utility requirements.
TABLE 1 - VOLTAGE LIMITATIONS
NOMINAL
VOLTAGE
UNIT
POWER
SUPPLY
VOLTAGE VARIATIONS
MIN. VOLTS MAX. VOLTS
600 575-3-60 540 630
480 480-3-60 432 504
240 230-3-60 216 252
208 200-3-60 182 218
Refer to Table 1 for voltage limitations and Table 9 on
page 27 for airflow and entering air/ambient condi-
tions limitations.
If the variable air volume (VAV) boxes in
the conditioned space have hydronic heat-
ing coils installed, it is the responsibility of
the installing contractor to take appropri-
ate measures to protect the hydronic coils
against low unit supply air temperatures
that could result in the freeze up and rup-
ture of the coils.
UNIT INSPECTION
Immediately upon receiving the unit, it should be
inspected for possible damage, which may have oc-
curred during transit. If damage is evident, it should
be noted in the carrier’s freight bill. A written request
for inspection by the carrier’s agent should be made at
once. See Shipping Damage Claims (Form 50.15-NM)
for more information and details.
To ensure warranty coverage, this equip-
ment must be commissioned and serviced
by an authorized Johnson Controls service
mechanic or a qualied service person
experienced in packaged rooftop instal-
lation. Installation must comply with all
applicable codes, particularly in regard to
electrical wiring and other safety elements
such as relief valves, HP cutout settings,
design working pressures, and ventilation
requirements consistent with the amount
and type of refrigerant charge.
Lethal voltages exist within the control
panels. Before servicing, open and tag all
disconnect switches.
LOCATIONS AND CLEARANCES
The following guidelines should be used to select a
suitable location for unit installation.
1. Unit is designed for outdoor installation only.
2. Condenser coils must have an unlimited supply of
air. Where a choice of location is possible, posi-
tion the unit on either north or east side of build-
ing.
3. Suitable for roof mount on curb.
