SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
OPERATING HOURS / START COUNTER
Compressor operating hours and compressor starts;
supply fan operating hours and supply fan starts; ex-
haust fan operating hours and exhaust fan starts; and
return fan operating hours and return fan starts are dis-
played via the OPERATING HOURS/START COUN-
TER key. The maximum value for both hours and starts
is 99,999, at which point they roll over to 0. See Table
50 on page 129 for the displays.
Below shows a typical screen example:
HOURS / STARTS OPER HRS. XXXXX
COMPRESSOR 1A STARTS XXXXX
TABLE 50 - OPERATING HOURS / START COUNTER
DISPLAY TEXT
PASS
WORD
LEVEL
RANGE DEFAULT
SETTING
LOCATION
SHOW WHEN
COMPRESSOR 1A OPER HRS
COMPRESSOR 1A STARTS
1 Derived
COMPRESSOR 1B OPER HRS
COMPRESSOR 1B STARTS
1 Derived
COMPRESSOR 2A OPER HRS
COMPRESSOR 2A STARTS
1 Derived
COMPRESSOR 2B OPER HRS
COMPRESSOR 2B STARTS
1 Derived
COMPRESSOR 3A OPER HRS
COMPRESSOR 3A STARTS
1 Derived
Number Of Comps 6. Unit Capacity
Equals 70 Ton, 75 Ton, 80 Ton, 90 Ton,
105 Ton
COMPRESSOR 3B OPER HRS
COMPRESSOR 3B STARTS
1 Derived
CONDENSER FAN 1A
CONDENSER FAN 1B
CONDENSER FAN 2A
CONDENSER FAN 2B
CONDENSER FAN 3A
Number Of Comps 6. Unit Capacity
Equals 70 Ton, 75 Ton, 80 Ton, 85 Ton, 90
Ton, 95 Ton, 105 Ton, 106 Ton, 110 Ton,
115 Ton, 130 Ton, 150 Ton.
CONDENSER FAN 3B
EXHAUST FAN OPER HRS
EXHAUST FAN STARTS
1 Derived
Power Exhaust On/Off Dmpr / On/Off
Press / Modulate Damper - VFD.
SUPPLY FAN OPER HRS
SUPPLY FAN STARTS
1 Derived
RETURN FAN OPER HRS
RETURN FAN STARTS
1 Derived
Supply System Type Equals Return Fan
W/Exh Return W/O Exhaust.
