SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
TABLE 46 - HEATING
DISPLAY TEXT
PASS
WORD
LEVEL
RANGE DEFAULT
SETTING
LOCATION
SHOW WHEN UNIT TYPE IS
HEATING SYS STATUS
Normal - Active /
Normal - Inactive
/ Faulted / User
Disabled / Under
Floor Control / None
Derived Always
HEATING SYSTEM
TYPE
2
None / Electric/
Staged Gas/
Modulating Gas/ Hot
Water/ Steam
None Options / Heating Always
GAS HEAT CAPACITY 2
375 Mbh / 750 Mbh /
1125 Mbh
375 Mbh Options / Heating
Heat Type Equals Staged Gas
Or Modulating Gas
ELEC HEAT CAPACITY 2
40 Kw - 200V
40 Kw / 80 Kw /
80 Kw - 200V/
100 Kw - 200V/
100 Kw / 120 Kw/
160 Kw / 200 Kw /
240 Kw
40 Kw Options / Heating Heat Type Equals Electric
SUPPLY AIR TEMP
CURRENT -20.0°F To 180.0°F
Look Up
Table
Heat Type Does Not Equal
None
ACTIVE SP 50.0°F To 120.0°F Derived
ZONE TEMP*
CURRENT -20.0°F To 180.0°F
Look Up
Table
Always
OCC ZONE HEATING
SETPOINT
1
60.0°F To Occ Zone
Cooling Setpoint
-2.0°F
68.0°F Setpoints / Heating
ZONE TEMP*
CURRENT -20.0°F To 180.0°F
Look Up
Table
Always
UNOCC ZONE
HEATING
SETPOINT
1
50.0°F To Unocc
Zone Cooling
Setpoint -2.0°F
60.0°F Setpoints / Heating
RETURN AIR TEMP
CURRENT -20.0°F To 180.0°F
Look Up
Table
Heat Type Does Not Equal
None And Unit Equals
Variable Air Volum Or
FLEXSYS
RAT HEATING
SETPOINT
1
55.0°F - RAT Cooling
Setpoint -2.0°F
68.0°F Setpoints / Heating
HEAT ENTERING
TEMP
-20.0°F To 180.0°F
Look Up
Table
Heat Type Equals Staged Gas
STAGED HEAT STATUS
STGS ON 0 To 6 Derived
Heat Type Equals Electric Or
Staged Gas
STGS AVAL 2 To 6 Derived
