Johnson Controls 100 Series - TABLE 16 - Gas Heat Performance Data

JOHNSON CONTROLS
50
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 3 – START-UP
TABLE 16 - GAS HEAT PERFORMANCE DATA
UNIT
GAS INPUT CAPACITY
(BTU/HR X 1000)
MAXIMUM OUTPUT CAPACITY
(BTU/HR X 1000)
AIRFLOW
TEMP. RISE (°F)
MIN. MAX.
70-85
375 300 6,950 27,750 10-40
750 600 11,150 27,750 20-50
1125 900 15,150 33,325 25-55
90-105
375 300 6,950 27,750 10-40
750 600 11,150 27,750 20-50
1125 900 15,150 33,325 25-55
