Johnson Controls 100 Series User Manual

JOHNSON CONTROLS
125
SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
TABLE 48 - VENTILATION
DISPLAY TEXT
PASS
WORD
LEVEL
RANGE DEFAULT
SETTING
LOCATION
SHOW WHEN UNIT TYPE IS
VENT SYS
STATUS
Normal - Active/
Normal - Inactive
/ Faulted / User
Disabled / None
Derived Always
DAMPER
HARDWARE
2
None / 2 Position/
Standard/ Tek Air
Full IAQ
Standard
Dampers
Options /
Ventilation
Always
VENTILATION
CONTROL
1
Fixed Minimum /
Demand
Fixed
Minimum
Options /
Ventilation
Damper Hardware Does Not Equal
None Or 2 Position
OA DAMPER POSITION
CURRENT 0–100% Derived
Damper Hardware Does Not Equal
None
ACTIVE SP 0–100% Derived
VENTILATION
DEMAND
0–100% Derived Ventilation Control Equals Demand
CO
2
LEVEL
OUTSIDE 0–2000 PPM Look Up Table
Ventilation Control Equals Demand
INSIDE 0–2000 PPM Look Up Table
CO
2
OFFSET
CURRENT ± 0–2000 PPM Derived
Ventilation Control Equals Demand
SETPOINT 1 100–1000 PPM 500 PPM
Setpoints /
Ventilation
OA DAMPER
MINIMUM
POSITION
1
0 to OA Damper
Maximum Position
15%
Setpoints /
Ventilation
Damper Hardware Does Not Equal
None Or 2 Position Damper
OA DAMPER
MAXIMUM
POSITION
1
OA Damper
Minimum Position
To 100%
30%
Setpoints /
Ventilation
Damper Hardware Does Not Equal
None Or 2 Position Damper
CONTINUOUS
VENT
1
User Enabled User
Disabled
User Enabled
Program /
Ventilation
Unit Type Equals Constant Volume
COMFORT
VENTILATION
1
User Enabled User
Disabled
User Disabled
Program /
Ventilation
Unit Type Equals Constant Volume
OUTSIDE AIR
MINIMUM FLOW
1
Minimum - Derived
Span X 5%
Maximum - The
Lower Of Derived
Span X 50%
And Outside Air
Maximum Flow
Derived Span
X 15%
Setpoints /
Ventilation
Damper Hardware Tek-Air Control Set
To Demand
OUTSIDE AIR
MAXIMUM
FLOW
1
Minimum - Outside
Air Minimum Flow
Maximum - Derived
Flow
Derived Span
X 30%
Setpoints /
Ventilation
Damper Hardware Tek-Air Control Set
To Demand
MINIMUM
OA FLOW
SETPOINT
1 0–100%
Derived Span
X 15%
Setpoints /
Ventilation
Damper Hardware Tek-Air And
Ventilation Control Set To Fixed
Minimum
VENTILATION
SYSTEM
1
User Enabled User
Disabled
User Enabled
Program /
Ventilation
Damper Hardware Does Not Equal
None
