JOHNSON CONTROLS
174
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 8 – SERVICE
TABLE 64 - I/O CONTROL BOARD - ANALOG INPUT PINOUTS
PIN
NUMBER
SIGNAL
J1-1 Input Supply Air Temp (308)
J1-5 Shield Supply Air Temp
J1-9 Ref Supply Air Temp 5VDC (309)
J1-2 Input Heat Enter Temp (310)
J1-6 Shield Heat Enter Temp
J1-10 Ref Heat Enter Temp 5VDC (311)
J1-3 Input Flex Evap Temp (312)
J1-7 Shield Flex Evap Temp
J1-11 Ref Flex Evap Temp 5VDC (313)
J2-1 Input Outside Air Temp (314)
J2-5 Shield Outside Air Temp
J2-9 Ref Outside Air Temp 5VDC (315)
J2-2 Input Return Air Temp (316)
J2-6 Shield Return Air Temp
J2-10 Ref Return Air Temp 5VDC (317)
J2-3 Input OA Hum (318)
J2-7 Com OA Hum (319)
J2-4 Input RA Hum (320)
J2-8 Com RA Hum (321)
J3-1 Input Suct Temp Sys1 (322)
J3-5 Shield Suct Temp Sys1
J3-9 Ref Suct Temp Sys1 5VDC (323)
J3-2 Input Suct Temp Sys2 (324)
J3-6 Shield Suct Temp Sys2
J3-10 Ref Suct Temp Sys2 5VDC (325)
J3-3 Input Suct Temp Sys3 (326)
J3-7 Shield Suct Temp Sys3
J3-11 Ref Suct Temp Sys3 5VDC (327)
J3-4 Input Suct Press Sys1 (328)
J3-8 Com Suct Press Sys1 (329)
J3-12 Ref Suct Press Sys1 5VDC (330)
J4-1 Input Suct Press Sys2 (331)
J4-6 Com Suct Press Sys2 (332)
J4-11 Ref Suct Press Sys2 5VDC (333)
J4-2 Input Suct Press Sys3 (334)
J4-7 Com Suct Press Sys3 (335)
J4-12 Ref Suct Press Sys3 5VDC (336)
J4-3 Input Disch Press Sys1 (337)
J4-8 Com Disch Press Sys1 (338)
PIN
NUMBER
SIGNAL
J4-13 Ref Disch Press Sys1 5VDC (339)
J4-4 Input Disch Press Sys2 (340)
J4-9 Com Disch Press Sys2 (341)
J4-14 Ref Disch Press Sys2 5VDC (342)
J4-5 Input Disch Press Sys3 (343)
J4-10 Com Disch Press Sys3 (344)
J4-15 Ref Disch Press Sys3 5VDC (345)
J5-1 Input Gas Heat Status (542)
J5-6 Com Gas Heat Status (543)
J5-11 Ref Gas Heat Status 5VDC (541)
J5-2 Input OA Co2 (348)
J5-7 Com OA Co2 (349)
J5-3 Input RA Co2 (350)
J5-8 Com RA Co2 (351)
J6-1 Input Return Fan Press (352)
J6-6 Com Return Fan Press (353)
J6-2 Input Duct Press (354)
J6-7 Com Duct Press (355)
J6-3 Input Bldg Press (356)
J6-8 Com Bldg Press (357)
J6-4 Input OA Air Press 1 (358)
J6-9 Com OA Air Press 1 (359)
J6-5 Input OA Air Press 2 (360)
J6-10 Com OA Air Press 2 (361)
J7-1 Input Zone Temp Sensor (363)
J7-6 Shield Zone Temp Sensor (364)
J7-11 Ref Zone Temp Sensor 5VDC (362)
J7-2 Input FlexSys Slab Sensor (366)
J7-7 Shield FlexSys Slab Sensor (367)
J7-12 Ref FlexSys Slab Sensor 5VDC (365)
J7-3 Input FlexSys Under Floor Hum (368)
J7-8 Com FlexSys Under Floor Hum (369)
J7-4 Input Sat Reset (371)
J7-9 Com Sat Reset (372)
J7-14 Ref Sat Reset 5VDC (370)
J7-5 Input Duct Static Reset (374)
J7-10 Com Duct Static Reset (375)
J7-15 Ref Duct Static Reset 5VDC (373)
