JOHNSON CONTROLS
168
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 8 – SERVICE
TABLE 61 - CO
2
SENSOR OUTPUT
PPM CO
2
OUTPUT
VOLTAGE
VDC
PPM CO
2
OUTPUT
VOLTAGE
VDC
80 0.20 1120 2.80
160 0.40 1200 3.00
240 0.60 1280 3.20
320 0.80 1360 3.40
400 1.00 1440 3.60
480 1.20 1520 3.80
560 1.40 1600 4.00
640 1.60 1680 4.20
720 1.80 1760 4.40
800 2.00 1840 4.60
880 2.20 1920 4.80
960 2.40 2000 5.00
1040 2.60
TABLE 62 - FURNACE STATUS INPUT MODULATING GAS HEAT
MIN VOLTS
DC
MAX VOLTS
DC
MODULATING
FURNACE 1A
STATUS
FURNACE 1A
HIGH
STATUS
FURNACE 2
STATUS
FURNACE 3
STATUS
FURNACE 1B
STATUS
0.086 0.166 OFF OFF OFF OFF OFF
0.224 0.313 ON OFF OFF OFF OFF
0.361 0.461 OFF ON OFF OFF OFF
0.499 0.609 ON ON OFF OFF OFF
0.637 0.756 OFF OFF ON OFF OFF
0.774 0.904 ON OFF ON OFF OFF
0.912 1.051 OFF ON ON OFF OFF
1.050 1.199 ON ON ON OFF OFF
1.187 1.346 OFF OFF OFF ON OFF
1.325 1.494 ON OFF OFF ON OFF
1.463 1.641 OFF ON OFF ON OFF
1.600 1.789 ON ON OFF ON OFF
1.738 1.936 OFF OFF ON ON OFF
1.876 2.084 ON OFF ON ON OFF
2.013 2.231 OFF ON ON ON OFF
2.151 2.379 ON ON ON ON OFF
2.289 2.526 OFF OFF OFF OFF ON
2.426 2.674 ON OFF OFF OFF ON
2.564 2.821 OFF ON OFF OFF ON
2.702 2.969 ON ON OFF OFF ON
2.839 3.116 OFF OFF ON OFF ON
2.977 3.264 ON OFF ON OFF ON
3.115 3.411 OFF ON ON OFF ON
3.252 3.559 ON ON ON OFF ON
