JOHNSON CONTROLS
118
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
SECTION 6 – USER INTERFACE CONTROL CENTER
DISPLAY TEXT
PASS
WORD
LEVEL
RANGE DEFAULT
SETTING
LOCATION
SHOW WHEN UNIT TYPE IS
ACTIVE SLAB CONTROL 1
User Enabled User
Disabled
User Disabled
Program/
Cooling
Unit Type Equals FLEXSYS
1ST STAGE COOLING
SETPOINT
1 55.0°F To 60.0°F 60.0°F
Setpoints/
Cooling
Unit Type Equals Constant
Volume
2ND STAGE COOLING
SETPOINT
1 55.0°F To 60.0°F 55.0°F
Setpoints/
Cooling
Unit Type Equals Constant
Volume
SAT LOW SETPOINT 1 55.0°F To 60.0°F 55.0°F
Setpoints/
Cooling
Unit Type Equals Variable Air
Volum
SAT HIGH SETPOINT 1 55.0°F To 60.0°F 65.0°F
Setpoints/
Cooling
Unit Type Equals Variable Air
Volum
OAT SETPOINT FOR
LOW SAT 1
OAT Setpoint For
High Sat To 90.0°F
80.0°F
Setpoints/
Cooling
Unit Type Equals Variable Air
Volum And Sat Reset Method
Equals Outside Temp
HIGH SAT 1
60.0°F To OAT
Setpoint For Low Sat
70.0°F
Setpoints/
Cooling
Unit Type Equals Variable Air
Volum And Sat Reset Method
Equals Outside Temp
RAT SETPOINT FOR
LOW SAT 1
RAT Setpoint For
High RAT +5.0°F To
90.0°F
90.0°F
Setpoints/
Cooling
Unit Type Equals Variable Air
Volum And Sat Reset Method
Equals Return Temp
HIGH SAT 1
RAT Cooling
Setpoint To RAT
Setpoint For Low Sat
-5.0°F
80.0°F
Setpoints/
Cooling
Unit Type Equals Variable Air
Volum And Sat Reset Method
Equals Return Temp
FAN SPEED SETP FOR
LOW SAT 1
Fan Speed Setp For
High Sat To 100%
90%
Setpoints/
Cooling
Unit Type Equals Variable Air
Volum And Sat Reset Method
Equals Supply Fan Speed
HIGH SAT 1
50% To Fan Speed
Setp For Low Sat
70%
Setpoints/
Cooling
Unit Type Equals Variable Air
Volum And Sat Reset Method
Equals Supply Fan Speed
EVAP LEAVING AIR
TEMP HIGH
1 50.0°F To 60.0°F 60.0°F
Setpoints/
Cooling
Unit Type Equals FLEXSYS
EVAP LEAVING AIR
TEMP LOW
1 50.0°F To 60.0°F 50.0°F
Setpoints/
Cooling
Unit Type Equals FLEXSYS
RESET ENTHALPY SP 2 25 To 35 BTU 30 Btu/#
Setpoints/
Cooling
Unit Type Equals FLEXSYS
SUP AIR TEMPERING 2
User Enabled User
Disabled
User Disable
Program/
Cooling
Unit Type Equals Variable Air
Volum Or FLEXSYS
MECH CLG LOCKOUT
TEMP
1 0.0°F To 65.0°F 50.0°F
Setpoints/
Cooling
Press Trans Pkg And Low
Ambient Pkg Other Than None
MECH CLG LOCKOUT
TMP MINIMUM
2 -10.0°F To 0.0°F 0.0°F
Setpoints/
Cooling
Press Trans Pkg And Low
Ambient Pkg Other Than None
* Only the zone temp screen for the current active mode is shown.
TABLE 43 – COOLING (CONT'D)
