JOHNSON CONTROLS
123
SECTION 6 – USER INTERFACE CONTROL CENTER
FORM 100.50-NOM12
ISSUE DATE: 04/02/2019
6
DISPLAY TEXT
PASS
WORD
LEVEL
RANGE DEFAULT
SETTING
LOCATION
SHOW WHEN UNIT TYPE IS
ADAPT MORN WARM
UP
1
User Enabled User
Disabled
User
Disabled
Program / Heating
Heat Type Does Not Equal
None And Constant Volume
Control Method Does Not
Equal Staged
NIGHT SET BACK 1
User Enabled User
Disabled
User
Disabled
Program / Heating
Heat Type Does Not Equal
None
HEAT LIMIT
TEMPERATURE
2 100.0°F to 150.0°F 130.0°F Setpoints / Heating
Heat Type Does Not Equal
None
HEATING SAT 1 80.0°F to 115.0°F 100.0°F Setpoints / Heating
Heat Type Does Not Equal
None, Unit Type Equals
Variable Air Volum, FlexSys
HW VALVE ACTION 2 Direct - Reverse Direct Program / Heating
Heating Type Equals Hot
Water Steam
IST STAGE HEATING
SETPOINT
1 80.0°F to 95.0°F 85.0°F Setpoints / Heating
Heat Type Does Not Equal
None And Unit Type Equals
Constant Volume
2ND STAGE HEATING
SETPOINT
1 95.0°F to 115.0°F 100.0°F Setpoints / Heating
Heat Type Does Not Equal
None And Unit Type Equals
Constant Volume
DAILY WARM UP TIME
DAY 1
0 Min. To Morning
Warm Up Max Time
Derived
Heat Type Does Not Equal
None And Morn Warm Up
Equals Enabled
DAILY WARM UP TIME
DAY 2
0 Min. To Morning
Warm Up Max Time
Derived
Heat Type Does Not Equal
None And Morn Warm Up
Equals Enabled
DAILY WARM UP TIME
DAY 3
0 Min. To Morning
Warm Up Max Time
Derived
Heat Type Does Not Equal
None And Morn Warm Up
Equals Enabled
DAILY WARM UP
TIMER
0 Min. To Morning
Warm Up Max Time
Derived
Heat Type Does Not Equal
None And Morn Warm Up
Equals Enabled
MORNING WARM UP
OPT TIME
0 Min. To Morning
Warm Up Max Time
Derived
Heat Type Does Not Equal
None And Morn Warm Up
Equals Enabled
MORNING WARM UP
MAX TIME
1 15–240 Min. 120 Min. Setpoints/Heating
Heat Type Does Not Equal
None And Morn Warm Up
Equals Enabled
* Only the zone temp screen for the current active mode is shown.
TABLE 46 – HEATING (CONT'D)
